Caterpillar C18 D 599 kW @ 2100 rpm - IMO II / EPA Tier 3 base

Engine

• Model Name:
  C18 D 599 kW @ 2100 rpm - IMO II / EPA Tier 3 base
• Range:
  C18
• Manufacturer:
  Caterpillar

Engine description

• No' of Cylinders:
  6
• Cylinder displacement:
  3 Litres
• Valves:
  SOHC
• Cooling system:
  Water

Performance data

• Bore
  145mm .
• Stroke
  183mm .
• Rotation:
  CCW(Standard Rotation)

Combustion parameters

• Fuel consumption:
  158 Litres
• Barometric pressure:
  1,000 mbar

Exhaust

• Exhaust emissions:
  IMO Tier II/EU Stage III A/EPA Tier 3

Dimensions

• Height:
  1,300mm .
• Width:
  1,134mm .
• Length without gearbox:
  1,854mm .
• Total displacement:
  18 Litres
• Mass
  1,950kg

Other

• In production?
  Yes
• Solas Compliance?
  No
